I am a technician at European Auto in Whitehouse/Tyler, Tx.
I had to change the fuel filter in a couple of MINI's the other day and thought I would take some pics of the process for you guys.
Here we go....
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
This image has been resized. Click this bar to view the full image. The original image is sized 1280x960.
